GR-CG / Precision racks & gears
Build-to-print internal/external rings, splines, shaft gears and special interfaces.
PRODUCT INFORMATION
Process route is set from material, tooth geometry, heat treatment, datums, inspection and batch size.
INDUSTRIES & APPLICATIONS
Explore the product’s role in equipment and the operating conditions to check during design.
Custom equipment and special motion
Drawing-based sections, holes, teeth and end connections suit constrained fixtures, transfer or rotary mechanisms. Confirm mating parts and assembly datums first.
Explore this industry
Industrial automation and robotics
Indexing drives on rotary assembly and inspection tables require checks of angular positioning, reversal backlash, cycle time, rotary support and preload interfaces.
Explore this industryTECHNICAL DATA
| Scope | Internal/external rings, splines and shaft gears |
|---|---|
| Processes | Hobbing, shaping, milling and grinding |
| Heat treatment | Drawing- and life-specific |
| Inspection | Profile, lead, runout and CMM |
PRODUCTION & INSPECTION
Equipment, process control and inspection records safeguard consistency from material through delivery.
Datum and mounting faces are ground first to establish a stable basis for tooth processing, heat treatment and inspection.
Module, tooth form and pitch govern cutter position, tooth-space consistency and machining allowance.
Heating, travel, cooling and distortion are controlled to achieve tooth hardness and wear resistance.
A five-face machining centre completes long-rack profiles, mounting faces, hole patterns and end interfaces with fewer set-ups.
Dedicated rack grinders finish tooth profile, lead and pitch under controlled cooling for precision transmission.
CMM, tooth-profile, pitch and manual checks verify dimensions, tooth accuracy, hardness and mounting interfaces.
PROJECT INQUIRY
Share load, travel, speed, accuracy, quantity or drawing data. We will assess selection, manufacturing and lead time.
