GR-MR / Precision racks & gears
Precision drive components for machine tools, automation and positioning systems.
PRODUCT INFORMATION
Configured to your module, length, tooth form, material and heat-treatment requirements.
INDUSTRIES & APPLICATIONS
Explore the product’s role in equipment and the operating conditions to check during design.
Machine tools and long-travel equipment
Sectional racks extend longitudinal feeds on gantry machining centres. Selection considers cutting force, pitch error, joint accuracy and mounting stiffness.
Explore this industry
Industrial automation and robotics
Linear transfer of fixture pallets in packaging and assembly lines uses sectional racks for extended travel. Confirm duty cycle, positioning requirements and lubrication access.
Explore this industryTECHNICAL DATA
| Manufacturing process | Milling, shaping, hardening or precision grinding according to drawing and accuracy |
|---|---|
| Module & tooth form | Calculated from load, speed, accuracy and mating pinion |
| Length & joining | Single or matched sections according to project travel |
| Material & heat treatment | Selected for operating conditions, service life and flank hardness |
| Engineering support | Calculation, selection, drawing review and lead-time assessment |
PRODUCTION & INSPECTION
Equipment, process control and inspection records safeguard consistency from material through delivery.
Datum and mounting faces are ground first to establish a stable basis for tooth processing, heat treatment and inspection.
Module, tooth form and pitch govern cutter position, tooth-space consistency and machining allowance.
Heating, travel, cooling and distortion are controlled to achieve tooth hardness and wear resistance.
A five-face machining centre completes long-rack profiles, mounting faces, hole patterns and end interfaces with fewer set-ups.
Dedicated rack grinders finish tooth profile, lead and pitch under controlled cooling for precision transmission.
CMM, tooth-profile, pitch and manual checks verify dimensions, tooth accuracy, hardness and mounting interfaces.
PROJECT INQUIRY
Share load, travel, speed, accuracy, quantity or drawing data. We will assess selection, manufacturing and lead time.
