GR-R7 / Integrated automation & robotics
Robot seventh-axis track
High-speed, high-stiffness track extending the working envelope of industrial robots.
- Product category
- Integrated automation & robotics
- Product code
- GR-R7
- ENGINEERING
- Customised to drawing and operating conditions
PRODUCT INFORMATION
Product overview
For long travel, multi-station and heavy robots, supplied with track, rack, drive, lubrication and protection.
INDUSTRIES & APPLICATIONS
Industries and specific applications
Explore the product’s role in equipment and the operating conditions to check during design.
Industrial automation and robotics
Machine loading and process transfer
Transfer parts between lathes, machining centres and adjacent stations. Size the drive and guidance for combined part/gripper mass, cycle time, acceleration and chip protection.
Explore this industryTECHNICAL DATA
Technical data & configuration
| Motion axis | External robot seventh axis |
|---|---|
| Drive | Precision rack and pinion |
| Travel | Modular long travel |
| Application | Welding, handling and machining cells |
Product, engineering and application references
PRODUCTION & INSPECTION
From production to inspection
Equipment, process control and inspection records safeguard consistency from material through delivery.
Surface grinding
Datum and mounting faces are ground first to establish a stable basis for tooth processing, heat treatment and inspection.
Rack-tooth milling
Module, tooth form and pitch govern cutter position, tooth-space consistency and machining allowance.
Induction hardening
Heating, travel, cooling and distortion are controlled to achieve tooth hardness and wear resistance.
Five-face machining
A five-face machining centre completes long-rack profiles, mounting faces, hole patterns and end interfaces with fewer set-ups.
Rack-tooth grinding
Dedicated rack grinders finish tooth profile, lead and pitch under controlled cooling for precision transmission.
Precision inspection
CMM, tooth-profile, pitch and manual checks verify dimensions, tooth accuracy, hardness and mounting interfaces.
