Automation solution image | Axes, payload and work envelope are project-configured
GR-GAN / Integrated automation & robotics
Custom gantry automation for payloads from 10 kg to 10,000 kg.
PRODUCT INFORMATION
Three-axis systems, high-speed heavy-load solutions and robot seventh-axis floor tracks.
INDUSTRIES & APPLICATIONS
Explore the product’s role in equipment and the operating conditions to check during design.
Industrial automation and robotics
Transfer parts between lathes, machining centres and adjacent stations. Size the drive and guidance for combined part/gripper mass, cycle time, acceleration and chip protection.
Explore this industryIndustrial automation and robotics
X/Y/Z motion handles picking, lifting and station transfer. Coordinate gripper mass, working envelope, vertical-axis braking and multi-axis cycle time.
Explore this industryTECHNICAL DATA
| Payload range | 10 kg - 10,000 kg (catalogue range) |
|---|---|
| System configuration | Single-axis, three-axis gantry systems and robot seventh-axis tracks |
| Design focus | Speed, heavy load, long travel and stable repeatability |
| Application | Loading, automotive feeding and heavy-duty handling |
PRODUCTION & INSPECTION
Equipment, process control and inspection records safeguard consistency from material through delivery.
Datum and mounting faces are ground first to establish a stable basis for tooth processing, heat treatment and inspection.
Module, tooth form and pitch govern cutter position, tooth-space consistency and machining allowance.
Heating, travel, cooling and distortion are controlled to achieve tooth hardness and wear resistance.
A five-face machining centre completes long-rack profiles, mounting faces, hole patterns and end interfaces with fewer set-ups.
Dedicated rack grinders finish tooth profile, lead and pitch under controlled cooling for precision transmission.
CMM, tooth-profile, pitch and manual checks verify dimensions, tooth accuracy, hardness and mounting interfaces.
PROJECT INQUIRY
Share load, travel, speed, accuracy, quantity or drawing data. We will assess selection, manufacturing and lead time.
GR-GA1
Integrated automation & robotics
Modular single-axis gantry for loading, transfer and linear handling.
View product →
GR-R7
Integrated automation & robotics
High-speed, high-stiffness track extending the working envelope of industrial robots.
View product →
