GR-GA1 / Integrated automation & robotics
Modular single-axis gantry for loading, transfer and linear handling.
PRODUCT INFORMATION
Rack, guide, beam, drive and guarding are configured from travel, payload, speed and repeatability.
INDUSTRIES & APPLICATIONS
Explore the product’s role in equipment and the operating conditions to check during design.
Industrial automation and robotics
Linear transfer of fixture pallets in packaging and assembly lines uses sectional racks for extended travel. Confirm duty cycle, positioning requirements and lubrication access.
Explore this industry
Industrial automation and robotics
Transfer parts between lathes, machining centres and adjacent stations. Size the drive and guidance for combined part/gripper mass, cycle time, acceleration and chip protection.
Explore this industryTECHNICAL DATA
| Axes | 1 axis |
|---|---|
| Payload | Project engineered |
| Travel | Long travel with joined sections |
| Application | Loading, transfer and conveying |
PRODUCTION & INSPECTION
Equipment, process control and inspection records safeguard consistency from material through delivery.
Datum and mounting faces are ground first to establish a stable basis for tooth processing, heat treatment and inspection.
Module, tooth form and pitch govern cutter position, tooth-space consistency and machining allowance.
Heating, travel, cooling and distortion are controlled to achieve tooth hardness and wear resistance.
A five-face machining centre completes long-rack profiles, mounting faces, hole patterns and end interfaces with fewer set-ups.
Dedicated rack grinders finish tooth profile, lead and pitch under controlled cooling for precision transmission.
CMM, tooth-profile, pitch and manual checks verify dimensions, tooth accuracy, hardness and mounting interfaces.
PROJECT INQUIRY
Share load, travel, speed, accuracy, quantity or drawing data. We will assess selection, manufacturing and lead time.
GR-GAN
Integrated automation & robotics
Custom gantry automation for payloads from 10 kg to 10,000 kg.
